Saber 9.50mm TiN Coated M2-HSS Jobber Drill 5 Pack

$55.00

In Stock


Calculate Shipping



Free pick-up from store - $0.00
Click and collect from our Deception Bay, Brisbane store

  • Saber 9.50mm TiN Coated M2-HSS Twist Drill
  • DIN338
  • 135º Split Point (crankshaft point).
  • Split point is self centering and the short distance from the drill axis to the outer corners results in faster penetration, reducing end thrust.
  • The 135º point should be used to cut harder steel materials especially in deep hole applications.
  • In these situations it will produce thicker chips minimising work hardening of the cavity.
  • Faster penetration reduces abrasion and friction along the cutting edges.
  • Gold Finish TiN Coating (Titanium Nitride) helps to dissipate heat and reduces friction and cold welding.
  • The coating higher speed and feed rates can be achieved and tool life is greatly increased.
  • The TiN coating is achieved by Physical Vapour Deposition (PVD).
  • As with all surface coated tools, performance will deteriorate after resharpening.

(8010-9.50)

Part Number: 8010-9.50
Brand: Saber
Pack Qty: 5
Feed per revolution mm: 0.19
Spindle Speed Aluminium/Brass RPM: 2045
Spindle Speed Cast Iron RPM: 805
Spindle Speed Free Cutting Steel RPM: 1442
Spindle Speed Malleable Iron RPM: 905
Spindle Speed Med. Carbon Steel RPM: 1006
Spindle Speed Stainless Steel RPM: 402
Spindle Speed Tool Steel RPM: 603
Spindle Speed Wood/Plastic RPM: 3051
Diameter (mm): 9.5
Flute Length (mm): 81
Overall Length (mm): 125
SKU 8010-9.50
Brand Saber
Shipping Weight 0.4000kg
Shipping Width 0.220m
Shipping Height 0.050m
Shipping Length 0.050m
Shipping Cubic 0.000550000m3
